RADAR ZA SPRECAVANJE UDARA ZA RAMPU ZA PARKING DAHUA DHI-ITSJC-2303-DC12

Opis

MODEL : DHI-ITSJC-2303-DC-1279 GHZ ANTI-SMASHING RADAR. USES THE LATEST ALGORITHM TO FILTER INTERFERENCE AND IS SUITABLE FOR ADVERTISING BARRIERS, FENCE ARM BARRIERS, STRAIGHT ARM BARRIERS, AND FOLDING ARM BARRIERS. ADJUSTABLE DETECTION DISTANCE AND WIDTH, APPLICABLE TO MULTIPLE SCENES. SUPPORTS UPDATING THROUGH SERIAL PORT AND MOBILE APP (WITH WI-FI CONNECTION), AND ALLOWS ONLINE COMMISSIONING AND FIRMWARE UPDATE. THE RADAR READS THE SURROUNDINGS AUTOMATICALLY, WHICH MAKES IT APPLICABLE TO COMPLICATED SCENES. CONNECTS TO CAMERAS THROUGH RS-485 TO OBTAIN PARAMETERS AND WORKING LOGS OF THE RADAR ON CAMERA WEB INTERFACE.SPECIFICATION : EMISSION FREQUENCY 77 GHZ?81 GHZ, EMISSION POWER 10 MW, BEAM WIDTH VERTICAL: ? 10?, HORIZONTAL: ? 36?, RESPONSE TIME 50 MS, DETECTION REGION 0.3 M?6 M (0.98 FT?19.69 FT) (ADJUSTABLE), ANTI-SMASHING REGION 0 M?2 M (0 FT?6.56 FT) (ADJUSTABLE), FUNCTION DETECTION TARGET, HUMAN, VEHICLE, ONLINE COMMISSIONING YES, THROUGH SERIAL PORT OR MOBILE APP (WITH WI-FI CONNECTION), UPDATE YES, THROUGH SERIAL PORT OR MOBILE APP (WITH WI-FI CONNECTION), PORT RS-485 1, I/O 2 (1 FOR UPDATE INPUT, 1 FOR RELAY OUTPUT), GENERAL OPERATING VOLTAGE 9 V?12 V DC, OPERATING CURRENT < 0.25 A, POWER CONSUMPTION < 3 W, OPERATING TEMPERATURE ?40 ?C TO +85 ?C (?40 ?F TO +185 ?F), PROTECTION GRADE IP66, PRODUCT DIMENSIONS 96 MM ? 60 MM ? 16.4 MM (3.78″ ? 2.36″ ? 0.65″) (L ? W ? H), NET WEIGHT 70 G ? 10 G (0.15 LB ? 0.02 LB), GROSS WEIGHT 220 G ? 20 G (0.49 LB ? 0.04 LB), INSTALLATION CASE SIDE MOUNT
