RACK ORMAR 12HE 600X450 CRNI TEHNOX TN-19-12U-B-A

Opis

MODEL TN-19-12U-B-AG12U WALL MOUNTING CABINET, DYNAMIC BASIC 638.40X600X4500 MM, COLOR BLACK (RAL 9005), 450 MM DEPTH PROVIDES A SPACE SAVING INSTALLATION, OPTIMIZED AIR VENTILATION AND EXHAUSTION, LOCKABLE SAFETY-GLASS DOOR WITH STEEL FRAMETHE WALL MOUNTING CABINETS OF THE DYNAMIC BASIC SERIES ARE MADE OF A ROBUST STEEL CONSTRUCTION. STABILITY IS GIVEN DUE TO THE WELDING SPOTS. THE SIDE SECTIONS ARE DETACHABLE AND THE INSTALLATION ON THE WALL IS EASY SO IT CAN BE IMPLEMENTED QUICKLY. DUE TO THEIR FLEXIBILITY THE CABINETS ARE IDEAL FOR ALL CURRENT IT AND TELECOMMUNICATION APPLICATIONS.TECHNICAL DETAILS : SAFETY CLASS RATING IP20, LOCKABLE SAFETY-GLASS DOOR WITH STEEL FRAME, 483 MM (19?) PROFILE RAILS MOUNTED ON THE FRONT SIDE INSIDE OF THE CABINET, GALVANIZED, 483 MM (19?) PROFILE RAILS ARE ADJUSTABLE IN DEPTH AND WITH HEIGHT UNIT MARKING, 0.8 – 1.2 MM STRONG SHEET STEEL WITH HIGH LOAD CAPACITY, POWDER COATED, CABLE ENTRY ON THE REAR SIDE, ROOF AND BASE (PRE-PUNCHED BREAK-OUTS), ROOF IS PREPARED FOR FAN UNITS (PUNCHED OUT ENTRIES), VENTILATION SLOTS FOR ACTIVE AND PASSIVE VENTILATION AND EXHAUSTING, 3 EARTHING POINTS (BASE, SIDE PANEL AND FRONT DOOR), MOUNTING LEVEL: FRONT SIDE, TYPE OF PROFILE RAIL: L-SHAPED, NUMBER OF DOORS: 1, TYPE OF VENTILATION: PASSIVE, WIDTH: 600 MM, HEIGHT: 638.4 MM, DEPTH: 450 MM, MODULAR SPACING: 482.6 MM (19 INCH), NUMBER OF HEIGHT UNITS: 12, TYPE OF SURFACE: WITH POWDER COATING, COLOUR:BLACK, MODEL: WITH PERMANENT FRAME, RAL-NUMBER: 9005, DEGREE OF PROTECTION (IP): IP20
